Franke hood Box Inox 52 cm FBI 525 XS Italy

General

• Type: Built-in (integrated) range hood
• Finish: Matte white
• Installation: Built-in

Features

• Number of lights: 2
• Lighting type: LED S2000, 4000 K
• Remote control: No
• Water-resistant: No
• Control type: Direct-wired/mechanical control
• Number of speeds: 3
• Intensive speed setting: No
• 24-hour air refresh function: No
• Delayed shut-off (run-on timer): No
• Automatic start sensor: No
• Wi-Fi connectivity: No
• Filter type: Cassette
• Grease filter material: Aluminum
• Charcoal filter included: No
• • Width: 522 mm (52.2 cm)
  • Height: 305 mm (30.5 cm)
  • Depth: 284 mm (28.4 cm)
  • Duct outlet diameter: 150 mm (a 120 mm reducer is often included)

  Installation Size




  Width   : 522 mm
  Height  : 305 mm
  Depth   : 284 mm
  Outlet  : Ø150 mm




  This model is designed to be installed inside a kitchen cabinet and is typically suitable for cabinets around 60 cm wide.

  If you're fitting it into existing cabinetry, I can also help determine the required cabinet cut-out dimensions and minimum mounting clearances.




Performance

Speed 1

• Airflow (IEC 61591): 180 m³/h
• Maximum pressure: 220 Pa
• Power consumption: 80 W
• Noise level (IEC 60704-3): 54 dB(A)

Speed 2

• Airflow (IEC 61591): 270 m³/h
• Maximum pressure: 240 Pa
• Power consumption: 90 W
• Noise level (IEC 60704-3): 62 dB(A)

Speed 3

• Airflow (IEC 61591): 390 m³/h
• Maximum pressure: 260 Pa
• Power consumption: 110 W
• Noise level (IEC 60704-3): 70 dB(A)

Dimensions

• Width: 522 mm
• Exhaust outlet diameter: 120 mm

Energy Specifications

• Plug type: Italian (IT)
• Annual energy consumption: 40.5 kWh/year
• Fluid Dynamic Efficiency Class: C
• Lighting Efficiency Class: A
• Grease Filtering Efficiency Class: C
• Energy Efficiency Class: B
• Motor voltage: 220–240 V, 50–60 Hz
• Motor type: Smart B
• Number of motors: 1

Additional Information

• Air quality sensor: No

Main Advantages

• Energy-efficient Class B rating
• Low annual energy consumption (40.5 kWh/year)
• Bright, efficient LED lighting
• Washable aluminum grease filters
• Compact built-in design suitable for integration into kitchen cabinetry
• Three extraction speeds for different cooking needs

This specification appears to be for a newer and more energy-efficient version of the Franke Box built-in hood than the older FBI 502-H XS (Class D) model.
